| Quantity: | |
|---|---|
YG018C6-R-3C
YOUTH GREEN
SPECIFICATIONS
Item Number | YG018C6 | YG018D9 | YG018E12 |
Cut Hole | 3” | 4” | 5” |
Type IC | YES | YES | YES |
Shape | Round | Round | Round |
Damp Locations | YES | YES | YES |
Air Tight | YES | YES | YES |
Finish | White | White | White |
PHOTOMETRIC
Color (CCT) | 3000K,4000K,5000K | 3000K,4000K,5000K, | 3000K,4000K,5000K |
Lumen | 500LM | 750LM | 1000LM |
CRI | >80 | >80 | >80 |
ELECTRICAL
Power(Wattage) | 6W | 9W | 12W |
Input Volts | AC120V | AC120V | AC120V |
Rated Lifetime | 50,000hrs | 50,000hrs | 50,000hrs |
Dimmable | Triac Dimming | Triac Dimming | Triac Dimming |
Power Factor | 0.97 | 0.97 | 0.97 |
IP Rated | IP44 | IP44 | IP44 |
Frequency | 60HZ | 60HZ | 60HZ |
Lumen Efficacy | 120LM/W | 90LM/W | 108LM/W |
Operating Temp | -40℃- 40℃ | -40℃- 40℃ | -40℃- 40℃ |
Warranty | 5 Years | 5 Years | 5 Years |
SPECIFICATIONS
Item Number | YG018C6 | YG018D9 | YG018E12 |
Cut Hole | 3” | 4” | 5” |
Type IC | YES | YES | YES |
Shape | Round | Round | Round |
Damp Locations | YES | YES | YES |
Air Tight | YES | YES | YES |
Finish | White | White | White |
PHOTOMETRIC
Color (CCT) | 3000K,4000K,5000K | 3000K,4000K,5000K, | 3000K,4000K,5000K |
Lumen | 500LM | 750LM | 1000LM |
CRI | >80 | >80 | >80 |
ELECTRICAL
Power(Wattage) | 6W | 9W | 12W |
Input Volts | AC120V | AC120V | AC120V |
Rated Lifetime | 50,000hrs | 50,000hrs | 50,000hrs |
Dimmable | Triac Dimming | Triac Dimming | Triac Dimming |
Power Factor | 0.97 | 0.97 | 0.97 |
IP Rated | IP44 | IP44 | IP44 |
Frequency | 60HZ | 60HZ | 60HZ |
Lumen Efficacy | 120LM/W | 90LM/W | 108LM/W |
Operating Temp | -40℃- 40℃ | -40℃- 40℃ | -40℃- 40℃ |
Warranty | 5 Years | 5 Years | 5 Years |
