Matte Black Bathroom Vanity Lights

Matte Black Bathroom Vanity Lights

• Size : 12inch (2 Head Lights), 20inch (3 Head Lights) ,24inch (4 Head Lights) ,30inch (5 Head Lights)

• Power: 10W 15W 20W 25W

• Lumen:768LM,1142LM,1520LM,1910LM

• IP Rate:IP44(Damp Locatios)

• 3CCT User Selectable 3000-4000-5000K

• CRI:80+

• Driver Input Voltage: 120V AC

• Default Driver Triac Dimmable 120v input

• Ambient Operating Temperature: (-39°C) to + (+40°C)

• Triac dimmable:5%-100% Dimmable.

• Warranty: 5 Year Commercial

• Certificates:ETL,ES,FCC

INSTRUCTIONS FOR PROPER ASSEMBLY

• Remove the screws fromthe lamp body for later use

• According to the hole position of the mountingplate,draw the distance of drilling on the wall, and turn the hole of 6mm on the wall with an electric drill

• Put the plastic granules packed by theaccessories into the opening hole

• The white line N-pole and black line L-poleof the lamp are connectedto the reserved powerline above the wall, and the ground wire is connected to the reserved ground wire above the wall.Align themounting hole position of the hardware disk with the mounting hole position of the mounting plate, and tighten the screws tosecure it to the wall
